Thursday, October 16, 2008

She did it raising nearly £6,000 for The Parkinsons Disease Society BTW! See Sarah's fundraising page here

Tuesday, October 14, 2008

It's Tuesday 14th and she's coming home!

Below you can see the finished fuel pump. I have extended it with steel rather than aluminium. Also that is in-tank hose being used!

So there it is, tank in place. The fuel system is complete. Just need to get some pipes made up by Ally Fab and the cooling system will be done too.

Wednesday, October 08, 2008

5/11 - Charca Huaylla Pass
No work on the car. A big walk for others.

Tuesday, October 07, 2008

Good progress was made over the weekend. As can be seen in the photo above, I have fitted the sender to the fuel tank and mounted the fuel filter. I also have plumbed in the radiator. I have had the hoses for ages but not managed to fit them because I could not finally fit the radiator as I needed something to put in the fan switch hole. I eventually got a switch from eBay. However I have just found out that Moss Europe sell an M22 x 1.5 blanking plug part number RFC014. In the picture you can just see that I have fitted the pedal box cover. This was made possible following the purchase of a rivnut setter. I bought a cheap rivnut tool a while back but it did not last long, the mandrel snapped. This time I bought Gesipa tool that should last a lifetime.

Another job waiting for the rivnut tool was the dash. Just need to fit the instruments and switches.
I have ordered a wiring loom from Premier Wiring Systems . I think £120 is good value for a loom with the correct colour wires. They are putting in extra wires and relays for fan, speedo and fuel pump and wiring the hazard switch! I'm going to use microphone cable to extend the Vepor speedo sensor cable. It is a VR sensor so has very low output and is suseptible to interference. Microphone cable is shielded twisted pair with very good noise rejection.

4/11 - no mobile signal. Will be another productive weekend!

Saturday, October 04, 2008

11 days to go......

Friday, October 03, 2008

The master cylinder that Sylva supplies for a Riot originates from a Caterham 7. It is Girling part number 74066147. I am led to believe that is has an 11/16", 17.46 mm bore. Since driving the latest Sylva demonstrator, which is fitted with a Willwood 1" bore master cylinder, I'm keen to increase the master cylinder size as I really liked the feel of the brake pedal. I could just fit the Willwood cylinder, but this means modifying the pedal box, something I'm not keen to do.
I noticed that Caterham supply a 13/16" 20.64 mm bore master cylinder made by AP racing, part number 77176. From the picture below you can just make out that it even has an SVA compliant cap.

The standard master cylinder has an affective bore area of 239.42 and the AP product, 334.63. That is an increase of almost 40%. Sounds perfect! Problem is it is £164.50!

Thursday, October 02, 2008

The picture below shows the Focus exhaust manifold attached to a Sylva silencer as requested.
You may notice the engine now has a fan belt! As the engine is from a Focus, the alternator and tensioner are from a 1250 Fiesta, it's little wonder that neither a Focus or Fiesta belt fits! The crank pulley on the Focus is larger diameter than the Fiesta. I could have changed the pulley but that means redoing the cam timing; the Zetec SE has a keyless crank. So I investigated a different belt. The standard 1250 Fiesta belt is 1181 long. Looking at the Gates catalogue, the most suitable belt would seem to be 6PK1195, 14mm longer. This belt is fitted to BMW 750i and a Fiat Punto 1.9D! It also fits my Riot perfectly.

I'm now working on the fuel tank and pump. Just waiting for some 8mm high pressure in-tank hose to be delivered. This is important as standard fuel hose is designed to convey fuel but not to be fully immersed in it! May have the tank in this weekend!
